105601100BQF Stearns Brake Assembly

105601100BQF Stearns Brake Assembly

The 105601100BQF is a Stearns Series 56000 solenoid actuated spring-set disc brake designed for industrial motor applications requiring reliable stopping power. It replaces compatible NEMA 2 enclosure brakes and is ideal for horizontal mounting in three-phase electrical systems.

Key Specifications

• Voltage: 208-230/460 V, 3-Phase
• Enclosure: NEMA 2 (IP23)
• Shaft Dimensions: 5/8" Hub Bore
• Rotation: Horizontal Mount
• Torque: 3 Foot Pounds
• Coil Insulation Class: B
• Maximum Speed: 5000 RPM

Product Features & Fitment

This brake features a manually adjusted, spring-set design with a solenoid for electrical release and includes a side manual release lever with automatic reset. It comes with 24-inch lead wires and a stamped steel housing. Adjustable torque and manual wear adjustment allow for precise control and maintenance. The brake is built to order with a typical lead time of one week.
