105602200BQF Stearns Brake Assembly
The 105602200BQF Stearns Brake Assembly is a solenoid-actuated, spring-set disc brake designed for electric motor applications requiring reliable stopping power. It replaces compatible NEMA 4 brakes and is ideal for industrial motors operating in horizontal mount configurations.
Key Specifications
- Voltage: 208-230/460 V
- Enclosure: IP23 (formerly NEMA 2)
- Shaft Dimensions: 5/8" hub bore
- Rotation: Horizontal mount
- RPM: Maximum 5000 RPM
Product Features & Fitment
This brake features manually adjustable torque with a side manual release lever and automatic reset functionality. It includes a 24-inch lead wire and Class B coil insulation. The stamped steel housing ensures durability, and the brake is designed for spring-set, electrically released operation. Lead time for shipment is approximately one week.
