T12S3G Nidec 1/2 hp 1200 RPM 56 Frame 575V TEFC 3-Phase Electric Motor
T12S3G Nidec 1/2 hp 1200 RPM 56 Frame 575V TEFC 3-Phase Electric Motor
T12S3G Nidec 1/2 hp 1200 RPM 56 Frame 575V TEFC 3-Phase Electric Motor
T12S3G Nidec 1/2 hp 1200 RPM 56 Frame 575V TEFC 3-Phase Electric Motor

Nidec

T12S3G Nidec 1/2 hp 1200 RPM 56 Frame 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$334.65
$298.66
SKU T12S3G
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 50/60 Hz
Amperage 0.85 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/2 hp 1200 RPM,  0.85 amps 575 Volts 50/60 Hz Three Phase Motor
  • NEMA 56 frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. T12S3G

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 50/60 Hz
Amperage 0.85 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
