T13C2JC Nidec 1/3 hp 1800 RPM 56C (Rigid Base) 115/208-230V TEFC 1-Phase Motor

SKU:
T13C2JC
Weight:
20.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $320.00
Now: $285.60
Adding to cart… The item has been added
  • 1/3 hp 1800 RPM, 6.6/3.0-3.3 amps  115/208-230 Volts 60 Hz Cap Start Single Phase Motor
  • NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor for pumps, conveyors, air compressors, and blowers. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. C055KKT4986015B
