T1CA2J14 Nidec 1 hp 1800 RPM 115/208-230V 143T Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

T1CA2J14 Nidec 1 hp 1800 RPM 115/208-230V 143T Frame (Rigid Base) 1-Speed TEFC Cap Start Motor

SKU:
T1CA2J14
Weight:
32.00 LBS
Width:
15.00 (in)
Height:
11.00 (in)
Depth:
12.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
115/208/230V
Horsepower:
1 HP
RPM:
1800
Frame:
143T
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
7.0 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Service Factor:
1.15
Insulation Class:
Class B
Mounting:
Rigid Base
Was: $764.75
Now: $683.10
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 14.0/6.9-7.0 amps 115/208-230V Volts 60 Hz Capacitor Start Motor
  • NEMA 56 Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = Auto
  • Rigid Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. C063JEF5310015B

!
