T2CA2J14 Nidec 2 hp 1800 RPM 115/208-230V 145T Frame (Rigid Base) 1-Speed TEFC Cap Start/Run Motor

54.00 LBS
Calculated at Checkout
  • 2 hp 1800 RPM, 18.9/10.3-9.4 amps 115/208-230V Volts 60 Hz Capacitor Start/Run Motor
  • NEMA 145T Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = Auto
  • Rigid Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. T063DCE1638015B
