T34C1JC Nidec 3/4 hp 3600 RPM 56C (Rigid Base) 115/208-230V TEFC 1-Phase Motor

T34C1JC Nidec 3/4 hp 3600 RPM 56C (Rigid Base) 115/208-230V TEFC 1-Phase Motor

SKU:
T34C1JC
Weight:
32.00 LBS
Width:
20.00 (in)
Height:
14.00 (in)
Depth:
10.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
115/208/230V
Horsepower:
3/4 HP
RPM:
3600
Phase:
Single Phase
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
5.2 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class B
Mounting:
Rigid Base
Was: $471.50
Now: $420.79
Adding to cart… The item has been added
  • 3/4 hp 3600 RPM, 10.4/5.3-5.2 amps  115/208-230 Volts 60 Hz Cap Start Single Phase Motor
  • NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor for pumps, conveyors, air compressors, and blowers. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. C063HZF5210015B

!
