U10P1G Nidec 10 hp 3600 RPM 215T Frame 575V TEFC 3-Phase Electric Motor
U10P1G Nidec 10 hp 3600 RPM 215T Frame 575V TEFC 3-Phase Electric Motor
U10P1G Nidec 10 hp 3600 RPM 215T Frame 575V TEFC 3-Phase Electric Motor
U10P1G Nidec 10 hp 3600 RPM 215T Frame 575V TEFC 3-Phase Electric Motor

Nidec

U10P1G Nidec 10 hp 3600 RPM 215T Frame 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$1,265.00
$1,129.76
SKU U10P1G
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 9.4 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 10 hp 3600 RPM, 9.4 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 215T frame Keyed Shaft 1 3/8" Diameter x 3 1/2"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. G60816

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 215T
Enclosure TEFC
Hertz 60 Hz
Amperage 9.4 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
