U10P2GC Nidec 10 hp 1800 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U10P2GC Nidec 10 hp 1800 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U10P2GC Nidec 10 hp 1800 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U10P2GC Nidec 10 hp 1800 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor

Nidec

U10P2GC Nidec 10 hp 1800 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$1,282.25
$1,145.17
SKU U10P2GC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 10 HP
RPM 1800
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 9.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 10 hp 1800 RPM, 9.6 amps  575 Volts 60 Hz Three Phase Motor
  • NEMA 215TC frame Keyed Shaft 1 1/8" Diameter x 2 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. CM19

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 10 HP
RPM 1800
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 9.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
