U5P3GC Nidec 5 hp 1200 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U5P3GC Nidec 5 hp 1200 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U5P3GC Nidec 5 hp 1200 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor
U5P3GC Nidec 5 hp 1200 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor

Nidec

U5P3GC Nidec 5 hp 1200 RPM 215TC Frame 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$1,446.70
$1,291.57
SKU U5P3GC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 5 HP
RPM 1200
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 5.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 5 hp 1200 RPM, 5.6 amps  575 Volts 60 Hz Three Phase Motor
  • NEMA 215TC frame Keyed Shaft 1 1/8" Diameter x 2 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. CK93

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 5 HP
RPM 1200
Phase Three Phase
Frame 215TC
Enclosure TEFC
Hertz 60 Hz
Amperage 5.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
