U14S3AC Nidec 1/4 hp 1200 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor
U14S3AC Nidec 1/4 hp 1200 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor
U14S3AC Nidec 1/4 hp 1200 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor
U14S3AC Nidec 1/4 hp 1200 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U14S3AC Nidec 1/4 hp 1200 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$302.45
$270.25
SKU U14S3AC
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/4 HP
RPM 1200
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60 Hz
Amperage 1.2/0.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/4 hp 1200 RPM,  1.1-1.2/0.6 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. F003

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/4 HP
RPM 1200
Phase Three Phase
Frame 56C
Enclosure TEFC
Hertz 60 Hz
Amperage 1.2/0.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
