U25P2DS Nidec 25 hp 1800 RPM 284TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U25P2DS Nidec 25 hp 1800 RPM 284TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U25P2DS Nidec 25 hp 1800 RPM 284TS Frame 208-230/460V TEFC 3-Phase Electric Motor
U25P2DS Nidec 25 hp 1800 RPM 284TS Frame 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U25P2DS Nidec 25 hp 1800 RPM 284TS Frame 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$2,325.30
$2,076.33
SKU U25P2DS
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284TS
Enclosure TEFC
Hertz 60 Hz
Amperage 59/29.3 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 25 hp 1800 RPM, 65-59/29.3 amps 208/230/460 Volts 60 Hz Three Phase Motor
  • NEMA 284TS frame Keyed Shaft 1 5/8" Diameter x 3 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. CM94

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284TS
Enclosure TEFC
Hertz 60 Hz
Amperage 59/29.3 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
