U2P1D Nidec 2 hp 3600 RPM 145T Frame 208-230/460V TEFC 3-Phase Electric Motor
U2P1D Nidec 2 hp 3600 RPM 145T Frame 208-230/460V TEFC 3-Phase Electric Motor
U2P1D Nidec 2 hp 3600 RPM 145T Frame 208-230/460V TEFC 3-Phase Electric Motor
U2P1D Nidec 2 hp 3600 RPM 145T Frame 208-230/460V TEFC 3-Phase Electric Motor

Nidec

U2P1D Nidec 2 hp 3600 RPM 145T Frame 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$492.20
$439.19
SKU U2P1D
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 145T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 4.9/2.5 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 3600 RPM, 5.4-4.9/2.5 amps  208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 145T frame Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. FD72
