U7P3G Nidec 7 1/2 hp 1200 RPM 254T Frame 575V TEFC 3-Phase Electric Motor
U7P3G Nidec 7 1/2 hp 1200 RPM 254T Frame 575V TEFC 3-Phase Electric Motor
U7P3G Nidec 7 1/2 hp 1200 RPM 254T Frame 575V TEFC 3-Phase Electric Motor
U7P3G Nidec 7 1/2 hp 1200 RPM 254T Frame 575V TEFC 3-Phase Electric Motor

Nidec

U7P3G Nidec 7 1/2 hp 1200 RPM 254T Frame 575V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$1,792.85
$1,600.46
SKU U7P3G
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 7.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 7 1/2 hp 1200 RPM, 7.6 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 254T frame Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DY93

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 7.6 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting Rigid Base
!
