UJ1P1BM Nidec 1 hp 3600 RPM 3-phase 143JM Frame 230/460V TEFC Close-Coupled Pump Motor
UJ1P1BM Nidec 1 hp 3600 RPM 3-phase 143JM Frame 230/460V TEFC Close-Coupled Pump Motor
UJ1P1BM Nidec 1 hp 3600 RPM 3-phase 143JM Frame 230/460V TEFC Close-Coupled Pump Motor
UJ1P1BM Nidec 1 hp 3600 RPM 3-phase 143JM Frame 230/460V TEFC Close-Coupled Pump Motor

Nidec

UJ1P1BM Nidec 1 hp 3600 RPM 3-phase 143JM Frame 230/460V TEFC Close-Coupled Pump Motor

(No reviews) Write a Review
$495.65
$442.64
SKU UJ1P1BM
Shipping Free Shipping
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1 HP
RPM 3600
Phase Three Phase
Frame 143JM
Enclosure TEFC
Hertz 60 Hz
Amperage 2.7/1.4 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 HP 3600 RPM, 2.7/1.4 amps, 230/460V 60hz. 3 Phase.
  • NEMA 143JM Rolled Steel Frame, JM stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, DZ90

Specifications
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1 HP
RPM 3600
Phase Three Phase
Frame 143JM
Enclosure TEFC
Hertz 60 Hz
Amperage 2.7/1.4 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
