UJ1P2GM US Motors 1 hp 1800 RPM 3-phase 143JM Frame 575V Close-Coupled Pump Motor
UJ1P2GM US Motors 1 hp 1800 RPM 3-phase 143JM Frame 575V Close-Coupled Pump Motor
UJ1P2GM US Motors 1 hp 1800 RPM 3-phase 143JM Frame 575V Close-Coupled Pump Motor
UJ1P2GM US Motors 1 hp 1800 RPM 3-phase 143JM Frame 575V Close-Coupled Pump Motor

US Motors

UJ1P2GM US Motors 1 hp 1800 RPM 3-phase 143JM Frame 575V Close-Coupled Pump Motor

(No reviews) Write a Review
$485.30
$433.32
SKU UJ1P2GM
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 143JM
Hertz 60 Hz
Amperage 1.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 1 HP 1800 RPM, 1.1 amps, 575V 60hz. 3 Phase.
  • NEMA 143JM Rolled Steel Frame, JM stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Removable Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TE = Totally Enclosed Fan Cooled, Proof, DT28

Specifications
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 143JM
Hertz 60 Hz
Amperage 1.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
