UJ3P2GM US Motors 3 hp 1800 RPM 3-phase 182JM Frame 575V Close-Coupled Pump Motor
UJ3P2GM US Motors 3 hp 1800 RPM 3-phase 182JM Frame 575V Close-Coupled Pump Motor
UJ3P2GM US Motors 3 hp 1800 RPM 3-phase 182JM Frame 575V Close-Coupled Pump Motor
UJ3P2GM US Motors 3 hp 1800 RPM 3-phase 182JM Frame 575V Close-Coupled Pump Motor

US Motors

UJ3P2GM US Motors 3 hp 1800 RPM 3-phase 182JM Frame 575V Close-Coupled Pump Motor

(No reviews) Write a Review
$745.20
$665.16
SKU UJ3P2GM
Availability Subject to availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182JM
Enclosure TEFC
Hertz 60 Hz
Amperage 3.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 3 HP 1800 RPM, 3.1 amps, 575V 60hz. 3 Phase.
  • NEMA 182JM Cast Aluminum Frame, JM stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Removable Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, DT31

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182JM
Enclosure TEFC
Hertz 60 Hz
Amperage 3.1 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
