UJ5P2DM US Motors 5 hp 1800 RPM 3-phase 182JM Frame 208-230/460V Close-Coupled Pump Motor
UJ5P2DM US Motors 5 hp 1800 RPM 3-phase 182JM Frame 208-230/460V Close-Coupled Pump Motor
UJ5P2DM US Motors 5 hp 1800 RPM 3-phase 182JM Frame 208-230/460V Close-Coupled Pump Motor
UJ5P2DM US Motors 5 hp 1800 RPM 3-phase 182JM Frame 208-230/460V Close-Coupled Pump Motor

US Motors

UJ5P2DM US Motors 5 hp 1800 RPM 3-phase 182JM Frame 208-230/460V Close-Coupled Pump Motor

(No reviews) Write a Review
$851.00
$759.69
SKU UJ5P2DM
Availability Subject to Availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 5 HP
RPM 1800
Phase Three Phase
Frame 182JM
Enclosure TEFC
Hertz 60 Hz
Amperage 15.3/7.7 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 5 HP 1800 RPM, 17.4-15.3/7.7 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 182JM Cast Aluminum Frame, JM stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Removable Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FK39

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 5 HP
RPM 1800
Phase Three Phase
Frame 182JM
Enclosure TEFC
Hertz 60 Hz
Amperage 15.3/7.7 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
