UN20T2GC Nidec 20 hp 1800 RPM 256TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor
UN20T2GC Nidec 20 hp 1800 RPM 256TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor
UN20T2GC Nidec 20 hp 1800 RPM 256TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor
UN20T2GC Nidec 20 hp 1800 RPM 256TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor

Nidec

UN20T2GC Nidec 20 hp 1800 RPM 256TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor

(No reviews) Write a Review
$2,479.40
$2,213.98
SKU UN20T2GC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 20 HP
RPM 1800
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 19.8 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 20 hp 1800 RPM, 19.8 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 256TC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable C-Face motor for material handling, cranes and machine tools. 5000:1 constant torque from 0 to nominal motor rpm. NEMA design A. Encoder and brake provisions. Wiring diagram on motor name plate. TENV = Totally-Enclosed Non-Ventilated. BV18

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 20 HP
RPM 1800
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 19.8 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
!
