UN3T2GC Nidec 3 hp 1800 RPM 182TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor

UN3T2GC Nidec 3 hp 1800 RPM 182TC (Rigid Base) 575V TENV Vector-Duty 3-Phase Motor

SKU:
UN3T2GC
Weight:
65.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $707.00
Now: $631.10
Adding to cart… The item has been added
  • 3 hp 1800 RPM, 4.1 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 182TC Rolled Steel Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.0 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable C-Face motor for material handling, cranes and machine tools. 5000:1 constant torque from 0 to nominal motor rpm. NEMA design A. Encoder and brake provisions. Wiring diagram on motor name plate. TENV = Totally-Enclosed Non-Ventilated. CF74

!
