VSP0504 TECO-Westinghouse 50 HP 1800 RPM 326VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor
VSP0504 TECO-Westinghouse 50 HP 1800 RPM 326VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor
VSP0504 TECO-Westinghouse 50 HP 1800 RPM 326VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor
VSP0504 TECO-Westinghouse 50 HP 1800 RPM 326VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor

TECO WESTINGHOUSE

VSP0504 TECO-Westinghouse 50 HP 1800 RPM 326VP 230/460V TEFC Vertical Solid Shaft 3-Ph Motor

(No reviews) Write a Review
$6,027.48
SKU VSP0504
Availability Subject to Availability
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326VP
Enclosure TEFC
Hertz 60 Hz
Amperage 116/58.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Rotation Counter-Clockwise
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE NEMA PREMIUM HIGH THRUST ELECTRIC MOTOR

  • 50 hp 1800 RPM, 116/58.3 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 326VP Frame, 1 5/8" Dia. x 4 1/2" Solid Keyed Shaft
  • Cast Iron Frame, Open Drip Proof (ODP)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • CCW Rotation Viewed From Top, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Vertical motor with "P" base and Weather Protected Type I (WPI) Enclosre. For use in fluid hangling systems, irrigation, fire-pumps, and deep well systems

Specifications
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326VP
Enclosure TEFC
Hertz 60 Hz
Amperage 116/58.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Rotation Counter-Clockwise
!
