WD12S2A Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TENV Washdown 3-Phase Motor
WD12S2A Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TENV Washdown 3-Phase Motor
WD12S2A Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TENV Washdown 3-Phase Motor
WD12S2A Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TENV Washdown 3-Phase Motor

Nidec

WD12S2A Nidec 1/2 hp 1800 RPM 56 Frame (Rigid Base) 208-230/460V TENV Washdown 3-Phase Motor

(No reviews) Write a Review
$477.25
$426.31
SKU WD12S2A
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56
Enclosure TENV
Hertz 50/60 Hz
Amperage 1.8/0.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/2 hp 1800 RPM, 1.9-1.8/0.9 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 56 Rolled Steel Frame with Cast Aluminum End Bells, Stainless Steel Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Painted washdown motor for use in food processing applications where frequent cleaning is required. Wiring diagram on motor name plate. TENV = Totally-Enclosed Non-Ventilated. P063GBJ4448025B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56
Enclosure TENV
Hertz 50/60 Hz
Amperage 1.8/0.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
