sale
Nidec
WD1P2AC Nidec 1 hp 1800 RPM 56C Frame (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
(No reviews)
Write a Review
Write a Review
Nidec
WD1P2AC Nidec 1 hp 1800 RPM 56C Frame (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
$725.65
$648.37
SKU
WD1P2AC
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
208/230/460V
Horsepower
1 HP
RPM
1800
Phase
Three Phase
Frame
56C
Enclosure
TENV
Hertz
60 Hz
Amperage
3.3/1.8 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
WD1P2AC Nidec 1 hp 1800 RPM 56C Frame (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
This Nidec 1 horsepower, 1800 RPM three-phase motor is designed for washdown environments commonly found in food and pharmaceutical applications. It serves as a reliable replacement motor featuring a totally enclosed non-ventilated (TENV) design to prevent contamination and ensure durability.
Key Specifications
- Horsepower: 1 hp
- RPM: 1800
- Voltage: 208-230/460 V
- Amperage: 3.4-3.3/1.8 A
- Enclosure: Totally Enclosed Non-Ventilated (TENV)
- Frame / Diameter: NEMA 56C Rolled Steel Frame
- Shaft Dimensions: 5/8" Diameter x 1 7/8" Length
- Rotation: Reversible
- Bearings: Ball Bearings
Product Features & Fitment
This motor features a rigid base with a C-face mount for versatile installation options. The keyed shaft ensures secure coupling, while the Class F insulation enhances thermal protection. Wiring diagrams are conveniently located on the motor nameplate to assist with proper electrical connections.
Warranty
1 Year Manufacturer Warranty
1 Year Manufacturer Warranty
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 208/230/460V |
| Horsepower | 1 HP |
| RPM | 1800 |
| Phase | Three Phase |
| Frame | 56C |
| Enclosure | TENV |
| Hertz | 60 Hz |
| Amperage | 3.3/1.8 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
