- 2 hp 1800 RPM, 19.6/9.8 amps 115/230 Volts 60 Hz Capacitor Start/Run Single Phase Motor
- NEMA 56HC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.15 Overload protection = None
- C-Face Mount, Ball Bearings, Class F Insulation, Reversible
- 1 Year Manufacture Warranty
White epoxy coated wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. T063DGM1729015B
