WD2C2PHC Nidec 2 hp 1800 RPM 56HC White (Rigid Base) 115/230V TEFC 1-Phase Washdown Motor
WD2C2PHC Nidec 2 hp 1800 RPM 56HC White (Rigid Base) 115/230V TEFC 1-Phase Washdown Motor
WD2C2PHC Nidec 2 hp 1800 RPM 56HC White (Rigid Base) 115/230V TEFC 1-Phase Washdown Motor
WD2C2PHC Nidec 2 hp 1800 RPM 56HC White (Rigid Base) 115/230V TEFC 1-Phase Washdown Motor

Nidec

WD2C2PHC Nidec 2 hp 1800 RPM 56HC White (Rigid Base) 115/230V TEFC 1-Phase Washdown Motor

(No reviews) Write a Review
$878.60
$783.96
SKU WD2C2PHC
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 19.6/9.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 1800 RPM, 19.6/9.8 amps 115/230 Volts 60 Hz Capacitor Start/Run Single Phase Motor
  • NEMA 56HC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

White epoxy coated wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. T063DGM1729015B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 19.6/9.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
