WD3P1A14C Nidec 3 hp 3600 RPM 145TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P1A14C Nidec 3 hp 3600 RPM 145TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P1A14C Nidec 3 hp 3600 RPM 145TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P1A14C Nidec 3 hp 3600 RPM 145TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WD3P1A14C Nidec 3 hp 3600 RPM 145TC Frame (Rigid Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$991.30
$885.27
SKU WD3P1A14C
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Frame 145TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.2/3.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3 hp 3600 RPM, 8.1-7.2/3.6 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145TC Rolled Steel Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Easy cleaning painted wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DK55

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Frame 145TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.2/3.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
