WD3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WD3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WD3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$1,191.40
$1,063.98
SKU WD3P2DCR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.6/3.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 3 hp 1800 RPM, 8.2-7.6/3.8 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182TC Rolled Steel Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Easy cleaning painted wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DD50

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182TC
Enclosure TEFC
Hertz 60 Hz
Amperage 7.6/3.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
!
