WDS1P2ACR Nidec 1 hp 1800 RPM 143TC All-Stainless (No Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS1P2ACR Nidec 1 hp 1800 RPM 143TC All-Stainless (No Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS1P2ACR Nidec 1 hp 1800 RPM 143TC All-Stainless (No Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS1P2ACR Nidec 1 hp 1800 RPM 143TC All-Stainless (No Base) 208-230/460V TENV 3-Phase Washdown Motor

Nidec

WDS1P2ACR Nidec 1 hp 1800 RPM 143TC All-Stainless (No Base) 208-230/460V TENV 3-Phase Washdown Motor

(No reviews) Write a Review
$1,207.50
$1,077.67
SKU WDS1P2ACR
Availability Subject to Availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 2.9/1.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 1 hp 1800 RPM, 3.1-2.9/1.4 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 143TC Rolled Steel Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

All Stainless Steel wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. FP23

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 2.9/1.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
!
