WDS2P2ACR Nidec 2 hp 1800 RPM 145TC All-Stainless (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDS2P2ACR Nidec 2 hp 1800 RPM 145TC All-Stainless (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDS2P2ACR Nidec 2 hp 1800 RPM 145TC All-Stainless (No Base) 208-230/460V TEFC 3-Phase Washdown Motor
WDS2P2ACR Nidec 2 hp 1800 RPM 145TC All-Stainless (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

Nidec

WDS2P2ACR Nidec 2 hp 1800 RPM 145TC All-Stainless (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

(No reviews) Write a Review
$1,524.90
$1,361.49
SKU WDS2P2ACR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1800
Phase Three Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 5.4/2.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 2 hp 1800 RPM, 5.8-5.4/2.7 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145TC Rolled Steel Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

All Stainless Steel wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. DD45

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1800
Phase Three Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 5.4/2.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
!
