WDS3P1ACR Nidec 3 hp 3600 RPM 182TC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS3P1ACR Nidec 3 hp 3600 RPM 182TC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS3P1ACR Nidec 3 hp 3600 RPM 182TC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor
WDS3P1ACR Nidec 3 hp 3600 RPM 182TC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor

Nidec

WDS3P1ACR Nidec 3 hp 3600 RPM 182TC All-Stainless (Rigid Base) 208-230/460V TENV 3-Phase Washdown Motor

(No reviews) Write a Review
$1,906.70
$1,702.69
SKU WDS3P1ACR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 7.2/4.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3 hp 3600 RPM, 8.1-7.2/4.1 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182TC Rolled Steel Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

All Stainless Steel wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. DY55

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 7.2/4.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
