X15P2B Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

SKU:
X15P2B
Weight:
320.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,926.00
Now: $1,719.90
Adding to cart… The item has been added
  • 15 hp 1800 RPM, 37.0/18.3 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 254T Cast Iron frame Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.0, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group CD and class 2 group FG.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CR91
