X32P2BCR Nidec 1 1/2 hp 1800 RPM 145TC Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor
X32P2BCR Nidec 1 1/2 hp 1800 RPM 145TC Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor
X32P2BCR Nidec 1 1/2 hp 1800 RPM 145TC Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor
X32P2BCR Nidec 1 1/2 hp 1800 RPM 145TC Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor

Nidec

X32P2BCR Nidec 1 1/2 hp 1800 RPM 145TC Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor

(No reviews) Write a Review
$798.10
$712.77
SKU X32P2BCR
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 145TC
Enclosure TEFC
Hertz 60 Hz
Amperage 4.3/2.1 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 1 1/2 hp 1800 RPM, 4.3/2.1 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145TC Cast Iron Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.0, Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group D, class 2 group FG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FN51

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 145TC
Enclosure TEFC
Hertz 60 Hz
Amperage 4.3/2.1 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting C-Face
!
