X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor
X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor
X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor
X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor
X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor
X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor

Marathon

X442 Marathon 1/3 hp 208-230V 1075 RPM OPAO Shaft Down 48Z Frame Condenser Fan Motor

(No reviews) Write a Review
$197.00
$172.04
SKU MX442
UPC 7.23E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230V
Horsepower 1/3 HP
RPM 1075
Frame 48Z
Hertz 60 Hz
Amperage 2.0 Amps
Bearings Ball Bearings
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 1/3 hp 1075 RPM, 2.0 amps, 208-230 Volts 60 Hz, Permanent Split Capacitor (PSC)
  • NEMA 48Z Frame Keyed Shaft 1/2" Diameter x 6"
  • Service Factor = 1.0, Thermal Protection = Automatic
  • No Base, Reversible, Ball Bearings, Class B insulation
  • 1 Year Manufacture Warranty

Shaft Down Condenser Fan Motors are used in air conditioning coolant condenser units usually found outdoors. Shaft must be be vertical and pointed downward. OPAO = Open-Air-Over so motor must be in air-stream. 048A11O2064

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230V
Horsepower 1/3 HP
RPM 1075
Frame 48Z
Hertz 60 Hz
Amperage 2.0 Amps
Bearings Ball Bearings
Insulation Class Class B
!
