X50P1BS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X50P1BS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X50P1BS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X50P1BS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

Nidec

X50P1BS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

(No reviews) Write a Review
$7,231.20
$6,456.91
SKU X50P1BS
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 326TS
Enclosure TEFC
Hertz 60 Hz
Amperage 114.0/57.0 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 50 hp 3600 RPM, 114.0/57.0 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 326TS Cast Iron frame Keyed Shaft 1 7/8" Diameter x 3 3/4"
  • Service Factor: 1.0, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group CD and class 2 group FG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FB48

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 326TS
Enclosure TEFC
Hertz 60 Hz
Amperage 114.0/57.0 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting Rigid Base
!
