X7P2B Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X7P2B Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X7P2B Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor
X7P2B Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

Nidec

X7P2B Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

(No reviews) Write a Review
$1,416.80
$1,264.89
SKU X7P2B
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.6/9.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 7 1/2 hp 1800 RPM, 18.6/9.3 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 213T Cast Iron frame Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group D and class 2 group FG.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FJ22

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.6/9.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
