X909 Marathon 1/4 hp 1800 RPM 115V TEAO 48Y Frame Split-Phase Farm Motor

X909 Marathon 1/4 hp 1800 RPM 115V TEAO 48Y Frame Split-Phase Farm Motor

The X909 Marathon motor is a single-phase, general-purpose farm motor designed for reliable operation in agricultural applications. It is a direct replacement motor featuring a totally enclosed air-over (TEAO) design suitable for use in air streams.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1800
• Voltage: 115V, 60 Hz
• Amperage: 4.0 amps
• Enclosure: Totally-Enclosed Air-Over (TEAO)
• Frame / Diameter: NEMA 48Y Frame
• Shaft Dimensions: 1/2" Diameter x 1 1/2" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a split-phase design with a service factor of 1.0 and manual overload protection. It does not include a base and requires mounting in an air stream to ensure proper cooling due to its TEAO enclosure. The motor is equipped with ball bearings for enhanced durability and smooth operation.

Warranty

1 Year Manufacturer Warranty
