XJ3P1BM Nidec 3 hp 3600 RPM 182JM Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor

XJ3P1BM Nidec 3 hp 3600 RPM 182JM Frame 60 Hz 230/460V TEFC 3-Phase Hazardous Duty Motor

SKU:
XJ3P1BM
Weight:
90.00 LBS
Width:
21.00 (in)
Height:
12.00 (in)
Depth:
14.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
230/460V
Horsepower:
3 HP
RPM:
3600
Phase:
Three Phase
Frame:
182JM
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
7.8/3.9 Amps
Bearings:
Ball Bearings
Service Factor:
1.0
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $1,137.35
Now: $1,014.99
Adding to cart… The item has been added
  • 3 hp 3600 RPM, 7.8/3.9 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182JM Cast Iron Frame, JM pump shaft
  • Service Factor: 1.0, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group D, class 2 group FG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FL58

!
