XP0058 TECO-Westinghouse 5 HP 900 RPM 254T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

SKU:
XP0058
Weight:
330.00 LBS
Shipping:
Calculated at Checkout
$1,714.90
Adding to cart… The item has been added

TECO WESTINGHOUSE NEMA PREMIUM EXPLOSION PROOF MOTOR

  • 5 hp 900 RPM, 1-Speed, 15.0/7.52 amps, 230/460 Volts 60 Hz. Three Phase
  • 254T Cast Iron Frame, Shaft: 1 5/8" x 4 1/8" with Key
  • Ball Bearing, Reversible Rotation, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class F
  • Explosion Proof: Class I Div. 1 Group C and D, Class II Groups E, F, and G.
  • 1 Year Manufacture Warranty

Explosion Proof Motor For Use Where Ever Explosive Gases or Grain Dust May Be Present. Totally Enclosed Fan Cooled (TEFC)
