XP0108 TECO-Westinghouse 10 HP 900 RPM 284T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XP0108 TECO-Westinghouse 10 HP 900 RPM 284T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XP0108 TECO-Westinghouse 10 HP 900 RPM 284T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor
XP0108 TECO-Westinghouse 10 HP 900 RPM 284T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

TECO WESTINGHOUSE

XP0108 TECO-Westinghouse 10 HP 900 RPM 284T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

(No reviews) Write a Review
$2,982.79
SKU XP0108
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 10 HP
RPM 900
Phase Three Phase
Frame 284T
Enclosure TEFC
Hertz 60 Hz
Amperage 28.5/14.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE NEMA PREMIUM EXPLOSION PROOF MOTOR

  • 10 hp 900 RPM, 1-Speed, 28.5/14.2 amps, 230/460 Volts 60 Hz. Three Phase
  • 284T Cast Iron Frame, Shaft: 1 7/8" x 4 5/8" with Key
  • Ball Bearing, Reversible Rotation, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class F
  • Explosion Proof: Class I Div. 1 Group C and D, Class II Groups E, F, and G.
  • 1 Year Manufacture Warranty

Explosion Proof Motor For Use Where Ever Explosive Gases or Grain Dust May Be Present. Totally Enclosed Fan Cooled (TEFC)

Specifications
Voltage 230/460V
Horsepower 10 HP
RPM 900
Phase Three Phase
Frame 284T
Enclosure TEFC
Hertz 60 Hz
Amperage 28.5/14.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Rotation Reversible
!
