XP0752 TECO-Westinghouse 75 HP 3600 RPM 365TS Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

SKU:
XP0752
Weight:
1,085.00 LBS
Shipping:
Calculated at Checkout
$6,218.63
Adding to cart… The item has been added

TECO WESTINGHOUSE NEMA PREMIUM EXPLOSION PROOF MOTOR

  • 75 hp 3600 RPM, 1-Speed, 161/80.7 amps, 230/460 Volts 60 Hz. Three Phase
  • 365TS Cast Iron Frame, Shaft: 1 7/8" x 3 3/4" with Key
  • Ball Bearing, Reversible Rotation, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class F
  • Explosion Proof: Class I Div. 1 Group C and D, Class II Groups E, F, and G.
  • 1 Year Manufacture Warranty

Explosion Proof Motor For Use Where Ever Explosive Gases or Grain Dust May Be Present. Totally Enclosed Fan Cooled (TEFC)
