- 1/2 hp 1200 RPM, 10.0/5.0 amps 115/230 Volts 60 Hz Capacitor Start Motor
- NEMA 56 Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.0, Overload protection = Auto
- C-Face Mount, Ball Bearings, Class B Insulation, Reversible
- 1 Year Manufacture Warranty
General purpose Division 1 hazardous location motor for class 1 group CD, class 2 group EFG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. CH63ABS1037015B
