YC25P1BS Nidec 25 hp 3600 RPM 284TS Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

YC25P1BS Nidec 25 hp 3600 RPM 284TS Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
YC25P1BS
Weight:
390.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $4,508.00
Now: $4,024.70
Adding to cart… The item has been added
  • 25 hp 3600 RPM, 57.0/28.7 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 284TS Cast Iron frame Keyed Shaft 1 5/8" Diameter x 3 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FE78

!
