YC2P1B Nidec 2 hp 3600 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC2P1B Nidec 2 hp 3600 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC2P1B Nidec 2 hp 3600 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor
YC2P1B Nidec 2 hp 3600 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

Nidec

YC2P1B Nidec 2 hp 3600 RPM 145T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

(No reviews) Write a Review
$1,224.75
$1,093.88
SKU YC2P1B
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 145T
Enclosure TEFC
Hertz 60 Hz
Amperage 4.9/2.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 3600 RPM, 4.9/2.4 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145T Cast Iron frame Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CP19

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 145T
Enclosure TEFC
Hertz 60 Hz
Amperage 4.9/2.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
