YC30P1BS Nidec 30 hp 3600 RPM 286TS Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

YC30P1BS Nidec 30 hp 3600 RPM 286TS Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
YC30P1BS
Weight:
460.00 LBS
Width:
30.00 (in)
Height:
20.00 (in)
Depth:
24.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
230/460V
Horsepower:
30 HP
RPM:
3600
Phase:
Three Phase
Frame:
286TS
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
69.0/34.0 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $5,623.50
Now: $5,020.90
Adding to cart… The item has been added
  • 30 hp 3600 RPM, 69.0/34.0 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 286TS Cast Iron frame Keyed Shaft 1 5/8" Diameter x 3 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FE79

!
