Fasco D1170 Motor | 1/15 hp 1550 RPM CW 4.4" Diameter 115 Volts (Jenn Air)

Fasco D1170 Motor | 1/15 hp 1550 RPM CW 4.4" Diameter 115 Volts (Jenn Air)

The Fasco D1170 is a reliable replacement motor designed for Jenn Air appliances, specifically as a direct OEM substitute for the Jenn Air 80CR and Dayton 48GN66 models. It is ideal for applications requiring a compact, stud-mounted motor with clockwise shaft rotation.

Key Specifications

• Horsepower: 1/15 hp
• RPM: 1550
• Voltage: 115 Volts
• Amperage: 2.1 amps
• Frame / Diameter: 4.4" diameter
• Shaft Dimensions: 3/8" diameter x 2 1/2" length
• Rotation: Clockwise (CWSE)
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a stud mount with a bolt circle diameter of 3.89" for secure installation. The motor length excluding the shaft measures 4 3/4", making it suitable for compact spaces. Its ball bearing construction ensures durability and smooth operation in HVAC and appliance applications.

Cross Reference

• OEM direct replacement for Jenn Air 80CR. Dayton 48GN66

Warranty

1 Year Manufacturer Warranty
