C264 Marathon 1/2 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor

SKU:
C264
Weight:
35.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Was: $676.30
Now: $590.50
Adding to cart… The item has been added
  • 1/2 hp 1200 RPM, 9.4/4.7 amps 115/230 Volts 60hz. Capacitor Start Motor
  • NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled,

Marathon Model: 5KC49UN6065
Replaces Leeson C6C11FB2G, 110011.00
