C264 Marathon 1/2 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
(No reviews)
Write a Review
Write a Review
Marathon
C264 Marathon 1/2 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
$777.75
$679.08
SKU
MC264
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
115/230V
Horsepower
1/2 HP
RPM
1200
Phase
Single Phase
Frame
56
Enclosure
TEFC
Hertz
60 Hz
Amperage
9.4/4.7 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class B
Mounting
Rigid Base
- 1/2 hp 1200 RPM, 9.4/4.7 amps 115/230 Volts 60hz. Capacitor Start Motor
- NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.15, Overload protection = None
- Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled,
Marathon Model: 5KC49UN6065
Replaces Leeson C6C11FB2G, 110011.00
