D12CP3PH9 Nidec | 1/2 hp 1200 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

D12CP3PH9 Nidec | 1/2 hp 1200 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

This general-purpose single-phase electric motor is designed for a variety of industrial and HVAC applications requiring reliable performance. It replaces similar 1/2 hp motors and features a capacitor start for efficient operation.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1200
• Voltage: 115/230V, 60 Hz
• Amperage: 4.8/2.4 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56H Frame
• Shaft Dimensions: Keyed shaft, 5/8" diameter x 1 7/8" length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor includes a resilient base mount for stable installation and is equipped with Class B insulation for durability. It requires a capacitor start and does not include overload protection. Wiring diagrams are provided on the motor nameplate to assist with proper electrical connections.

Warranty

1 Year Manufacturer Warranty
