GF2054 Century 1/2 hp 1725 RPM 48 Frame 115V Belt Drive Furnace Motor

GF2054 Century 1/2 hp 1725 RPM 48 Frame 115V Belt Drive Furnace Motor

This Century 1/2 horsepower belt drive furnace motor is designed for residential HVAC applications, providing reliable blower operation. It is a direct replacement for many standard furnace blower motors requiring a 48 frame, 115V, 1725 RPM motor.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1725
• Voltage: 115V
• Amperage: 7.2 amps
• Frame / Diameter: 48 Frame
• Shaft Dimensions: 1/2" diameter x 1 1/2" length, 3" shaft height
• Rotation: Reversible
• Bearings: Sleeve Bearings
• Enclosure: Open Drip Proof

Product Features & Fitment

The motor features a resilient cradle base for stable mounting and includes a shaft adapter for 5/8" shafts. It supports continuous duty with automatic overload protection and a service factor of 1.25. Quick connect terminals and easy rotation change simplify installation and maintenance. This split phase motor uses Class B insulation and is well-suited for residential furnace blower applications.

Warranty

1 Year Manufacturer Warranty
