This Leeson 1/2 hp, 1800 RPM three-phase motor is designed for wash down duty applications, featuring a totally enclosed fan cooled (TEFC) design and durable construction. It replaces Marathon model N668 and is ideal for environments requiring moisture resistance and reliable performance.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 208-230/460V
• Amperage: 2.0/1.0 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 56C Frame
• Shaft Dimensions: 5/8" Diameter x 1 7/8" Length

Product Features & Fitment

This Leeson Washguard motor features a round body design without a base and includes a keyed shaft for secure coupling. Its construction incorporates stainless steel components such as the shaft, conduit box cover, nameplate, and fan guard, along with special gaskets, slingers, and seals for enhanced moisture resistance. The motor also includes four endshield drains and uses the IRIS insulation system to protect internal components in wash down environments.

Cross Reference

• Marathon N668, 056T17W99006

Warranty

1 Year Manufacturer Warranty
